Flamotubular Boiler Puerto Rico/H. FAC4
The Flamotubular Boilers Model Puerto Rico, from 1.000 kg to 40.000 kg are equipped with a cooled grate system, equipped with a combustion system with electronic fuel injection, which guarantees maximum efficiency at any load and operating condition.
Type: Flamotubular with inclined cooled grate
Steam: Saturated
Steam: Super heated
Capacity: 01 to 40 tons/h of steam
Working pressure:7.5 to 25 kgf/cm²
Main fuel: Firewood logs
Compact construction
Low operating costs
Execution of simple civil base, without intervention in the mechanical installation.
CO2 content 14 %, CO content: below 400 ppm - meeting ISO 14000 standard, Noise level can be below 85 dB at two meters from the source,
Gas temperature after air preheater 180°C, Access platforms, Insulation prepared for weather operation without the need for a boiler house,
Design and construction to ASME I standard.
Textile industry, Wood industry, Food industry, Rubber and plastic industry,
Paving industry, Paint and varnish industry, Pulp and paper industry, Chemical industry,
Laundries, Indirect heating of water or air, Heating systems in general,
Non-combustion steam generation systems, Printers and packaging machines.
